Honda All-Terrain Vehicles (ATV)

1987 ATC250ES Big Red 246cc

1987 ATC250SX 246cc

1987 TRX250 Fourtrax 246cc

1988 TRX300 281cc
1989 TRX300 281cc
1990 TRX300 281cc
1991 TRX300 281cc
1992 TRX300 281cc
1993 TRX300 281cc
1994 TRX300 281cc
1995 TRX300 281cc
1996 TRX300 281cc
1997 TRX300 281cc
1998 TRX300 281cc
1999 TRX300 281cc
2000 TRX300 281cc

1988 TRX300FW 281cc
1989 TRX300FW 281cc
1990 TRX300FW 281cc
1991 TRX300FW 281cc
1992 TRX300FW 281cc
1993 TRX300FW 281cc
1994 TRX300FW 281cc
1995 TRX300FW 281cc
1996 TRX300FW 281cc
1997 TRX300FW 281cc
1998 TRX300FW 281cc
1999 TRX300FW 281cc
2000 TRX300FW 281cc

Part Numbers

Honda
31200-HA0-773, 31200-HA0-774, 31200-HA6-306
31200-HA6-316, 31200-HA6-773, 31200-HA6-774
31200-HC4-003, 31200-HC4-013, 31200-HC4-023
31200-HC4-033

Mitsuba
SM13213

Nippondenso
128000-4400

Remy Small Motor
RS41181

Specifications

Type: PMDD
Voltage: 12 Volts
Rotation: CCW
Teeth/Splines: 10 Teeth/Splines
Pinion/Splines OD: 12.8 mm / 0.504 in
Mounting Hole 1: 6.5 mm ID Unthreaded
Mounting Hole 2: 6.5 mm ID Unthreaded
Approximate Weight: 3.59 lb / 1.63 kg
